Water Cooled Reciprocating Chiller

Water Cooled Reciprocating Chiller Specification

Air Flow
Not Applicable (Water Cooled)

Application
Industrial process cooling, HVAC, Chemical, and Pharmaceutical Cooling

Refrigerating Capacity
5 TR to 80 TR

Material
Mild Steel Powder Coated

Motor
Three Phase Induction Motor

Condition
New

Type
Water Cooled Reciprocating Chiller

Dimension (L*W*H)
Customizable (varies by model)

Power Supply
415 V AC, 50 Hz, 3 Phase

Voltage
415 V

Cooling Type
Water Cooled

Nozzle Material
PVC/Brass

Cooling Coil Material
Copper

Water Flowing Rate
2.5 m/h to 18 m/h (varies by model)

Water Pump Motor
0.75 HP to 2 HP

Noise Control
Below 70 dB(A)

Compressor
Hermetically Sealed Reciprocating Type

Pipe Connection Size
1 inch to 2.5 inch (varies by capacity)

Evaporator
Shell & Tube Type

Automation Grade
Automatic

Display
Digital Temperature Controller

Mounting
Skid Base Mounted

Ambient Temperature Range
5°C to 45°C

Serviceability
Easy Panel Access for Maintenance

Cooling Water Temperature Range
7°C to 25°C

Flow Control
Thermostatic Expansion Valve

Safety Features
Overload Protection, Low/High Pressure Cut-out, Phase Failure Relay

Condenser
Shell & Tube Water Cooled

Insulation Material
PUF / Nitrile Rubber

Capacity Control
Step or Smooth Unloading Mechanism

Refrigerant Used
R22/R407C/R134a

Water Cooled Reciprocating Chiller Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
1 , , Unit Per Week

Delivery Time
1 Week

About Water Cooled Reciprocating Chiller

Specification

Brand	MS Cool Engineers
Phase	Three
Refrigerant Used	R 22
Automation Grade	Automatic
Body Material	Mild Steel
Frequency	50/60 Hz
Usage/Application	Industrial
Country of Origin	Made in India
Chiller Type	Water Cooled
Surface Finish	Color Coated
Voltage	440 V
Compressor Type	Reciprocating Chiller
Tonnage	2 TR

Efficient Cooling Technology

Designed with a shell & tube type evaporator and condenser, this water cooled reciprocating chiller provides optimal thermal exchange, reducing operation costs while maintaining consistent cooling. The three-phase induction motor and hermetically sealed compressor ensure robust, stable performance across a wide ambient temperature range (5C to 45C).

Advanced Safety and Automation

Safety is prioritized with overload protection, low/high pressure cut-out, and phase failure relay. Automated through a digital temperature controller and thermostatic expansion valve, the chiller offers trouble-free operation and precise temperature regulation for critical processes.

Versatile and Customizable Solutions

Available with cooling water temperature ranges from 7C to 25C and water flowing rates between 2.5 m3/h and 18 m3/h, this chiller is adaptable for varying capacity and installation requirements. Customizable dimensions and multiple piping options allow seamless integration into diverse industrial settings.

FAQ's of Water Cooled Reciprocating Chiller:

Q: How does the water cooled reciprocating chiller work in industrial applications?

A: The chiller utilizes a reciprocating compressor to circulate refrigerant (R22, R407C, or R134a) through shell & tube heat exchangers, transferring heat from process water and expelling it via a water-cooled condenser. This process efficiently lowers water temperature, making it suitable for HVAC, chemical, and pharmaceutical cooling.

Q: What are the main benefits of the thermostatic expansion valve and digital temperature controller in this chiller?

A: The thermostatic expansion valve precisely controls refrigerant flow, optimizing energy efficiency and cooling performance. The digital temperature controller allows automated, accurate temperature management, reducing manual intervention and ensuring reliable operation.

Q: When should maintenance be performed on the water cooled reciprocating chiller?

A: Routine maintenance is recommended at regular intervals, depending on operating hours and usage. Thanks to its easy panel access, tasks such as inspecting insulation, cleaning heat exchangers, and checking pressure settings can be performed quickly and efficiently.

Q: Where can this chiller be installed, and what site requirements should be considered?

A: This chiller is suitable for indoor or sheltered industrial environments throughout India, requiring a stable three-phase 415V, 50Hz power supply and adequate water supply for cooling. Skid base mounting ensures secure installation and stability.

Q: What process or mechanism is used for capacity control in this chiller?

A: Capacity is regulated by either a step or smooth unloading mechanism, allowing the compressor to adjust output based on cooling demand. This approach enhances energy savings and adapts to varying process loads effectively.

Q: How does the chiller ensure operational safety during use?

A: Built-in safety features such as overload protection, low/high pressure cut-outs, and phase failure relay safeguard the compressor and electrical systems, minimizing risks and prolonging equipment life.
